Topcon X-63 - Stick Sensor Mounting

Installation
SensorInstallation
14
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
Stick Sensor Mounting
Locateacon venientsurfacetomountthesensor.Mountingthesensorclosetothetopofthestickwillhelp
preven tdamageduringdigging.
Therecommendedmountinglocationisontheleftsideofthestick(fromthecabpointofview)withthe
arrowpointingforwardtowardthedirectionoftr avel,whenthestickisextended(Figure17onpage14).
Ifmountingthesensoronthefr ontofthestick,makesurethesensorisparalleltothestick ‐to‐bucket
centerline(
Figure17).
Figure17:TS‐1StickSensorMounting
TS‐i3sensorsareonlymountedontheleftorrightofthestick.
Correct Front
Location
Correct Side
Location
(Recommended)
Incorrect
Incorrect
