X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
Bucket Edge Calibration
Performthefollowingbucketedgecalibrationproceduresforallbuckettypes.Thesecalibrationsmustalso
beperformedforeachindividualbucketwhenusingmultiple buckets.
1. SelectabucketfromtheExcavatorBucketsscreen.
2. Withthebucketplumb,tapCalibratefromtheCalibrateBucketEdgescreen(Figure45);tap
NexttogototheCalibrateBucketBasescreen.
Figure53:CalibrateBucketEdge
3. Movethebucketsothatthebottomofthebucketlaysflatontheground,andtapCalibrate;tap
FinishtogototheExcavatorBucketsscreen(Figure46).
Figure54:CalibrateBucketBase
Ifsettingupmultiplebucketsofanykind,skipto“MultipleBucketCalibration”onpage37
