Topcon X-63 - Verifying Setup; Range of Motion and String Line Verification

Calibration
MachineCalibration
39
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
9. Withthebucketinthisposition,tapSetnexttoPitch,enterthePitchvalueas0.0°,andtapSet
again.
10. TapSetnexttoRoll,entertheRollvalueas0.0°,andtapSetagain(Figure51).
Figure51:SetPitchandRolltoZero
11. TapOK;theExcavatorBucketSetupscreenappears(Figure52).
Figure52:BucketSetup
12. Ifthisisthelastsensorphysicallyconnectedtothemachine,see“CANTermination”onpage41.
Tocalibratethebucketedge,see“BucketEdgeCalibration”onpage35. Ifsettingupmultiple
bucketsofanykind,see“MultipleBucketCalibration” onpage37.
