Topcon X-63 - Boom Sensor Mounting

Installation
SensorInstallation
15
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
Boom Sensor Mounting
Fortheboomsensor,locate aconvenientsurfaceparalleltotheboomcenter.Therecommendedmounting
locationisup,onthetopoftheboom,withthearrowpointingforwardtowardthedirectionoftravel
(Figure18).
Ifmountingonthesideoftheboom,becausemanyboomswilltaperoutattheboompivot,besure
toplacethesensoratalocationawayfromtheboompivot 
Figure18:BoomSensorMounting
Placingtheboomsensoronataperedsectionwillcausecalculationerrors.
TS‐i3sensorsareonlymountedontheleftorrightoftheboom.
CL
Correct
Up Location
(Recommended)
CL
Correct
Side Location
CL
Incorrect Taper Location
Direction of Travel
