Topcon X-63 - Secondary Boom and Body Sensor Mounting

Installation
SensorInstallation
16
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
Secondary Boom Sensor Mounting (Optional)
Seetheprevioussection “BoomSensorMounting”onpage15forsecondaryboomsensormounting
locations.
Body Sensor Mounting
Forthebodysensor,locateaconvenientsurfaceparalleltotheboompivot.Thesensormustbelinedup
withthecenterlineoftheboom.Therecommendedmountinglocationisup,ontopofthebody,withthe
arrowpointingforwardtowardthedirectionoftr avel(Figure19).
Figure19:BodySensorMounting‐TopView
Boom Pivot
Body Sensor
Mount Body Sensor
Parallel to Boom Pivot
IfusingaTS‐i3sensor,mountiteitherontheleft,right,ortopofthebodywiththearrow
pointingtowardthedirectionoftravel.
