Installation
Sensor Installation
TS-1 Sensor Installation
EachTS‐1sensorcontainsa3‐axis360°sensorelementwhichmustbeconfigureddependingonthe
mountingposition.TheTS‐1TiltSensorscanbe mountedinmanyorientationsaslongastheyareparallel
totheaxisbeingmeasured(Figure12).Locatesurfacesthatprotectthesensorfromphysicaldamageand
areconvenientforcablerouting.Whenthepositionoftheimplementisatzerodegrees(horizontal),
makeanoteofthedirectionofthearrowmarkeronthesensornameplate.Thisdirectionisneeded
duringcalibration.Thecalibrationprocessuses3D‐MCtoenterdirection,orientation,andothersensor
variables.
TS-1 Sensor Orientation
Figure12:TS‐1ArrowMarkerLocationandDirection
Table3indicatesarrowmarkerdirectionoptionsoncethemountingsurfacehasbeenselecte d.These
directionsassumethemountingsurfaceisatzerodegrees.
Whenmountingthetiltsensors,beginwiththebuckettohelpsimplifycablerouting.
Table3.MarkerDirectionOptions
MountingSurface MarkerDirectionOptions
Back Right Up
Down Forward Right
Forward Right Up
Left Up Forward
Right Forward Up
Up Forward Right
Arrow Marker
Direction
of Travel
Left
Forward
Back
Down
Right
Up
Back
