Calibrating the Sensors
Oncethe sensorsarenamed,assignedtoamachineelement,andtheorientationisselected,
calibrateeachsensorusing3D‐MC.Asensorcalibrationcanbeperformedatanytime. 
Body Sensor Calibration
Thebodysensorcalibrationrequiresboththepitchandrollcalibrations.Performboth calibrationsat
thesametimetoensureaccuratemeas urements.
Figure27:BodyCalibrationsforLatitudinalSlope
1. Positionthemachineonaflatandstablesurface,freeofobstructions.
2. Curlthestickandbucketinascloseaspossibletoreducetippingerrors.
3. Rotatethebodyparalleltothetracks(position1).
4. In3D‐MC,tapTopconMenuButtonControlMachinesetup.Selecttheapplicablemachine
fileforthejob,andtapEdit.TapNexttonavigatetotheExcavatorFrame/Sensorsscreen.
5. TaptheWrenchiconthatcorrespondstothebodysensor.
Thebestpracticeistoperformthemachinecalibrationsasorderedinthismanual.
Performingthecalibrationsoutoforderwillnotaffectsystemperformance.Theexception
tothisiswhenusingadog‐bonesensor.Youmustcalibratethesticksensorbefore
calibratingthe dog‐bonesensor.
Starting Position
Rotate 180°
