Verifying Aux Antenna-to-Boom Length
ThepositionofthemainantennatotheauxantennadeterminesGPSheading.Thedistancefromtheaux
antennatotheboompivotdeterminestherotationalheadingofthemachine.Smallerrorsinthis
measuremen tmayhaveasignificantrotationalpositionerroratthebucket.Useoneofthemethodsbelow
todeterminetheadjustmentneededformeasurementerrorcorrection.
Figure74:AuxAntenna‐to‐BoomPivot
Aux
