Chapter 5 Product Flow Control
175
Firmware Version 3/4.31.37
Overrun Alarm Volume
20 gallons
Preset Setup
5.2.5 2”-3” DIGITAL CONTROL VALVES
Once the digital control valve, needle valve adjustments are correctly set, digital valve control is not a problem.
But with small 2”-3” digital valves or valves that do not contain needle valve adjusters, these valves tend to react
very quickly and sometimes result in constant overshooting of the target flow rate, especially at low flow rates.
This can be observed as the valve fails to lock into a steady flow rate while the solenoids continue to click
throughout the load.
To prevent this problem an alternative flow algorithm can be configured. This algorithm makes small steps in the
adjustment of the digital control valve eliminating the overshoot and allowing a reduction in the flow deadband
values. Changing the length of time the solenoid is strobed (Valve Dwell Time) will allow software adjustment of
the valve speed similar to the way a needle valve adjusts the valve speed.
MultiLoad can be configured to use this alternate digital control valve algorithm by configuring as follows:
Navigate to: Program Mode->Configuration->Equipment Setup and configure the following parameters:
Parameter
Setting
Screen Location
Flow Scan Time
0.200 Seconds
Meter Setup
Valve Dwell Time
0.060 Seconds
Meter Setup
To increase the speed of adjustment, increase the Valve Dwell Time by 0.005 up to no more than 0.170 seconds.
To decrease the speed of adjustment, decrease the Valve Dwell Time by 0.005 down to no less than 0.030
seconds.
5.2.6 ADAPTIVE DIGITAL CONTROL ALGORITHM
To increase the accuracy of targeting flow rates, an Adaptive Digital Control Valve Algorithm has been developed.
This algorithm notes the adjustment speed of the digital control valve with the current flow and valve conditions,
and adjusts its control method to target as close as possible to the target flow rate. Once locked into this target
flow rate the next adjustment will not occur until the current flow rate falls outside the target deadband.
With FCM or I/O Board versions 037 and later, MultiLoad can be configured to use this Adaptive Digital Control
Valve Algorithm by configuring as follows:
Navigate to: Program Mode->Configuration->Equipment Setup and configure the following parameters:
Parameter
Setting
Screen Location
Flow Scan Time
0.200 Seconds
Meter Setup
Adaptive Valve Control
ENABLED
Meter Setup
5.2.7 TWO STAGE VALVES
Two stage valves are similar to Digital control valves in that they both operate using Normally Open (NO) and
Normally Closed (NC) solenoids. The two stage valve provides only two flow rates however, Low and High.
MultiLoad can handle two stage valves through proper configuration as follows:
Navigate to: Program Mode->Configuration->Equipment Setup and configure the following parameters:
Preset
Meters
Components
Low Flow Rate: 5000
Low Flow DB Rate: 4999
High Flow Rate: 9999
High Flow Rate: 9999
1st Stage DB Rate: 4999
1st Stage Flow Rate: 5000
Excess Flw Alrm Rate:
> Max anticipated flow rate
2nd Stage Trip Vol: 0
Fallback Time: 0
