Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
270
Firmware Version 3/4.31.37
2. After Selection of the Sampler, the Sampler Diagnostics screen will be displayed. Only the I/O that is
configured will appear on this screen.
Permissive
Reads the FCM’s input port for stimulis and reports.
PermissOut
Applies stimulis to the FCM output port and reports.
Authorized
Applies stimulis to the FCM output port for flow and reports.
[x]Del Pulses
Initiates an injection. The number of sampler meter pulses expected from the
injection will appear to the right.
Del Pulses
Number of sampler pulses received from the sampler meter.
Del Volume
Total sampler volume injected.
8.23 TANKS (SCS ONLY)
Tank diagnostics enable your technician or electrician to diagnose wiring problems or hardware problems by
testing the wiring and control from the MultiLoad II to the gauging unit, valves, etc.
- Input statuses can be viewed as ON or OFF.
PRE #1 SAMP #1 DIAGNOSTICS
Permissive -OFF
[1]PermissOut -ON
[2]Authorized -OFF
[3]Alarm Out -OFF
[4]Del Pulses- 0
Del Pulses- 0
Del Volume- 0
Exit
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
