Firmware Version 3/4.31.37
8.18 METER DIAGNOSTICS
Meter diagnostics enable your technician or electrician to diagnose wiring problems or hardware problems by
testing the wiring and control from the MultiLoad II to outside devices such as digital control valves, flow meters,
and permissives.
- Input statuses can be viewed as ON or OFF.
- Outputs can be activated or deactivated from this screen by pressing the number that corresponds to the
function.
1. From the Diagnostics Menu, select Meters.
