Toptech Systems MultiLoad II SCS

Chapter 6 – Additive Control
236
Firmware Version 3/4.31.37
If the Injector Valve is in the flush path, as in the diagram below, it will have to be held open during the flush
phase. In such a case, enable the Solenoid Flushed parameter. The Injector Valve will then remain open during
the flush phase.
Add #1 Add #2
M
Additive
Meter
Additive Block Valve
Add #1
P
Flush Pump
Injector Valve
Figure 6.13 Additive Meter and Injector Valve in Flush Path
