Chapter 9 – Weights & Measures
Firmware Version 3/4.31.37
On means that the program mode bolt has been removed.
OFF means that the program mode bolt is inside the unit.
On means that the W&M bolt has been removed.
OFF means that the W&M bolt is inside the unit.
This will give the observed temperature in the unit and also the measured voltage.
Temperature will be given in F or C depending on the bay configuration.
Remaining flash battery capacity. At 0% the battery must be replaced.
This gives the last date and time the unit was powered on.
This gives the last date and time the unit was in program mode.
After powering on the unit Pwr and Pgm are equal!
8.16 BAY DIAGNOSTICS
Bay Diagnostics can be used to troubleshoot permissives at the Bay level.
- The bay permissive input statuses can be viewed as ON or OFF.
- The bay Permissive-Out, Authorized, and Alarm Out outputs can be activated or deactivated from this screen
by pressing the number that corresponds to the function.
1. From the Diagnostics Menu, select RCU.
2. The Bay Diagnostics screen displays: Only the I/O that is configured will appear on this screen.
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
