Toptech Systems MultiLoad II SCS User Manual

Chapter 13 – Custom Logic
412
Firmware Version 3/4.31.37
MSB FCM Address Bitwise Representation LSB
Custom Logic
1 bit
Enabled
1 bit
Invert
1 bit
FCM Number
5 bits
Port Number
6 bits
Examples
FCM
Number
Port
Number
Bitwise Representation
Numerical Value
1
4
0
1
0
00001
000100
4164
3
11
0
1
0
00011
001011
4299
13.2.4 REAL TIME ALARMS
The Real Time Alarms group gives you the ability to read the status of a specific alarm. If an alarm is active then
the value of that custom logic line will be 1, if it is inactive then it will be 0.
13.2.5 OPERATIONS
The Operations group gives you the ability to perform logical operations on one or more inputs to produce a single
output.
SELECT CUSTOM LOGIC R.T. ALARM PARAMETER
BAY ALARM
PRESET ALARM
COMPONENT ALARM
METER ALARM
ADDITIVE ALARM
SAMPLER ALARM
Next Prev Exit Enter
