Chapter 10– Views and Inquiries
Firmware Version 3/4.31.37
Parameter Descriptions:
Displays the live mA value that is being read by the analog input.
Displays the real-time BSW2.
Displays the current BSW2 offset value, which is the difference between the
BSW2 Unadjusted value and the BSW2 Adjusted (observed relative density)
value.
Displays the observed BSW2 as a result of applying the BSW2 offset.
10.10 VIEWING API GRAVITY
From the Views and Inquiry Menu select API Gravity. After selecting the preset and meter, the API Gravity
screen displays:
PRE #1 BSW2
BSW2 Input: 08.000mA
BSW2 Unadjusted: +25.00%
[1]BSW2 Offset: +0.00%
[2]BSW2 Adjusted: +25.00%
Next Prev Exit
PRE #1 MTR #1 API GRAVITY
API Gravity Input: 08.000mA
API Gravity Unadjusted: +275.0
[1]API Gravity Offset: +0.0
[2]API Gravity Adjusted: +275.0
Next Prev Exit
