Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
272
Firmware Version 3/4.31.37
Strt Trg Lvl
Reads the FCM’s input port for stimulis to start a transaction and reports.
Stop Trg Lvl
Reads the FCM’s input port for stimulis to stop a transaction and reports.
8.24 CUSTOM LOGIC
The Custom Logic diagnostic function is used to look at what the live value of each line is.
8.25 MODBUS DEVICE
The Modbus Device diagnostics screen allows you to send a single command to the slave device to verify that
everything is configured properly and working correctly. From here you can adjust the configuration and send
read/write commands to the device. The bottom of the screen will display exactly what was sent and received.
MODBUS DEVICE 01 DIAGNOSTICS
Device Name: Device 01___________________
Adjust Configuration
Command: READ 16-bit
Register#: 0
Write Value: 0
Send Command
Next Prev Exit Enter
CUSTOM LOGIC DIAGNOSTICS
[0000]=0000000000=UNUSED
[0001]=0000000000=UNUSED
[0002]=0000000000=UNUSED
[0003]=0000000000=UNUSED
[0004]=0000000000=UNUSED
[0005]=0000000000=UNUSED
[0006]=0000000000=UNUSED
[0007]=0000000000=UNUSED
[0008]=0000000000=UNUSED
[0009]=0000000000=UNUSED
[0010]=0000000000=UNUSED
[0011]=0000000000=UNUSED
[0012]=0000000000=UNUSED
[0013]=0000000000=UNUSED
Next Prev Exit
