Firmware Version 3/4.31.37
8.3 IBUTTON READER (EXCLUDING SMP)
Note: If the MultiLoad II is a SMP or does not have a iButton installed, this test is not applicable.
Use the iBUTTON function to verify the operation of ibutton and a driver card.
From the DIAGNOSTICS MENU, choose iBUTTON Reader.
The iButton Reader Test screen displays. After placing a ibutton at the reader the screen will update after each
read of the ibutton.
8.4 LOOPBACK TEST
The Loopback Test is used for two purposes:
- To test the transmit and receive capabilities of Host COM Port on MultiLoad II.
- To troubleshoot serial communication problems between MultiLoad II and the host system (TMS).
From the DIAGNOSTIC MENU, choose COM Loopback.
