Firmware Version 3/4.31.37
Figure 6.8 Vol/Inj Calculated
The third field will show how many cubic centimeters of additive will be delivered in 1000 gallons. This field is
only valid if the main product is delivered in gallons.
The fourth field will show the resulting pacing rate. The pacing rate is how often an injection will occur based on
the recipe percentage entered. In the example, an injection will occur for every 40 units of volume that are
delivered. If delivery is in gallons, the value of 40 often provides a nice, moderate rate of injection. When using
units other than gallons, enter the equivalent of 40 gallons in the pacing rate field. A vol/injection calculation will
result that should provide a moderate injection rate.
Following the pacing rate is the calculated volume per injection. This value should be used when configuring the
additive. Press the Enter button to have this value implemented for the selected additive.
6.9 REMOTE ADDITIVE CALIBRATION
The Remote Additive Calibration feature enables the technician to select, in advance, all of the additives that will
be tested in a calibration session. The injectors can be tested one right after the other without having to return to
the MultiLoad II to enter data. Observed additive volumes are entered at one time after all samples have been
measured and recorded.
The injections must be initiated by pushbuttons installed at the additive panels. To assign a pushbutton that is
installed at the additive panel, go to the Additive menu and select Test Button FCM#. Select a port that will
assign the pushbutton to an input port. This must be done for each additive that will be tested using Remote
Additive Calibration.
1. To begin the calibration procedure, enter Program mode and choose Configuration from the Main Menu.
2. Select Remote Adtv Cal and press Enter.
PRE #1 ADTV #1 (Adtv 001 ) CALCULATE
[1]Additive Percentage: 0.05000
[2]Additive Vol Per 1000: 0.5000
[3]Additive Vol Per 1000: 1892cc
[4]Additive Pacing Rate: 40.0
Additive Vol/Inject: 0.02000
Additive Vol/Inject: 75.71cc
Enter=Save Exit
