Chapter 6 – Additive Control
Firmware Version 3/4.31.37
2. The Following screen displays:
3. If the additive recipe percentage is known, Press the 1 button and key in the percentage. Calculated values
will appear in the remaining fields.
In the example, a percentage of .05% was entered. The second field shows the volume of additive that will result
in a load of 1000 volumetric units.
PRE #1 ADTV #1 (Adtv 001 ) CALCULATE
[1]Additive Percentage:
[2]Additive Vol Per 1000:
[3]Additive Vol Per 1000: cc
[4]Additive Pacing Rate: 40.0
Additive Vol/Inject:
Additive Vol/Inject: cc
Enter=Save Exit
PRE #1 ADTV #1 (Adtv 001 ) CALIBRATE
Automatic Calibration Function
Review Last Calibration Data
Calculate Additive Vol/Inject
Additive Vol/Inject: 0.0200
Additive Mtr K-Factr: 2600
Additive Mtr Factor: 1.0000
Next Prev Exit Enter
