2. After Selection of the Meter, the Meter Diagnostics screen displays. Only the I/O that is configured will
appear on this screen.
If the meter is configured to have an analog valve output, the following screen will appear.
Upstrm Val
Energize or deenergize the upstream solenoid valve.
Dnstrm Val
Energize or deenergize the downstream solenoid valve.
OPN/CLS Test
Start an automated test measuring the control valve opening and closing speeds.
Set Output xx mA
Set mA drive output to xx.
Output mA xx.xxxx
Display or Set mA drive output to xx.xxxx.
Del Pulses
Number of meter pulses received.
Del Volume
Meter volume delivered.
Input mA-
Current meter 4-20mA signal (Analog Meter Input Only).
Rate
Current flow rate.
PRE #1 MTR #1 DIAGNOSTICS
Permissive -OFF
[1]PermissOut -ON
[2]Authorized -OFF
[3]Alarm Out -OFF
[4]Set Output 0 mA
[5]Set Output 4 mA
[6]Set Output 12 mA
[7]Set Output 20 mA
[8]Output mA 00.000
Del Pulses- 0
Del Vol- 0.00
Rate- 0
Exit
PRE #1 MTR #1 DIAGNOSTICS
Permissive -OFF
[1]PermissOut -ON
[2]Authorized -OFF
[3]Alarm Out -OFF
[4]Upstrm Val -OFF
[5]Dnstrm Val -OFF
[6]OPN/CLS Test
Del Pulses- 0
Del Vol- 0.00
Input mA- +00.000
Rate- 0
Exit
