Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
263
Firmware Version 3/4.31.37
Turning on both Upstrm Val and Dnstrm Val at the same time will open the digital control valve
and may result in flow (if pumps, block valves, and dry breaks are set correctly).
Driving the mA output to any value greater than 4 mA will open the digital control valve and
may result in flow (if pumps, block valves, and dry breaks are set correctly).
If the meter is configured as a Krohne mass meter, the following screen will appear:
Mass Flow
The current flow rate in the configured mass flow units.
Volume Flow
The current flow rate in the configured volume flow units.
Density
The current density in the configured density units.
Temperature
The current temperature in the configure temperature units.
Mass Total
The total mass of product flowed since power on of the mass meter.
Volume Total
The total volume of product flowed since power on of the mass meter.
If the meter is configured as a Micro Motion mass meter, the following screen will appear:
PRE #1 MTR #1 KROHNE DIAGNOSTICS
Mass Flow: 0.000000kg/Min
Volume Flow: 0.000000USGal/Min
Density: 1.050000kg/m3
Temperature: 22.991680C
Mass Total: -0.002545kg
Volume Total: -0.670395USGal
[1]Communications
[2]Sensor Info
[3]General Setup
[4]Zero Calibration
[5]Density Calibration
[6]Service Page
[7]Register Access
[8]Service Register Access
Exit
!
!
