Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
251
Firmware Version 3/4.31.37
2. The Keypad Test screen displays:
3. Type: 1234567890
4. Press any key that is suspected of failure.
5. If a key is operating properly, its character will be displayed on the diagnostic screen each time the key is
pressed. If the character for a particular key does not appear on the screen when pressed, or appears
multiple times, it may be necessary to replace the keypad.
6. Any counts in the Checksum Errors or Missed could also indicate a keypad failure.
KEYPAD TEST
Checksum Errors: 00000 Firmware Ver: 000
Heartbeat: Received: 59478 Missed: 00000
Keys Pressed:
1234567890
Exit CLeaR
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
