Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
282
Firmware Version 3/4.31.37
Table
Description
ASTM1250-
1980 Table 54A
This table provides CTL factors for correcting volumes of crude oil at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is crude oil
 Density at 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 610-1075 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Note: Enabling the “Canada API Limits” bay parameter will extend the temperature range
down to -40 C in accordance with Measurement Canada Bulletin: V-18-E rev.3 1999-09-
19 section 270.
ASTM1250-
1980 Table 54B
This table provides CTL factors for correcting volumes of gasolines at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a refined product
 Density at 15 C is known (use table 53B if Density at observed temperature is used)
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 653-1075 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Note: Enabling the “Canada API Limits” bay parameter will extend the temperature range
down to -40 C in accordance with Measurement Canada Bulletin: V-18-E rev.3 1999-09-
19 section 270.
ASTM1250-
1980 Table 54C
This table provides CTL factors for correcting volumes of petroleum liquids at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a refined product or crude oil
 Coefficient of Expansion @ 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Coefficient of Thermal Expansion (alpha) of the liquid at
15 C. The valid range of alpha is from 0.000486-0.001674. The alpha will be entered as
486-1674, however. Test temperatures can be entered on this screen that will calculate a
CTL based on the test temperature and the alpha. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Note: Enabling the “Canada API Limits” bay parameter will extend the temperature range
down to -40 C in accordance with Measurement Canada Bulletin: V-18-E rev.3 1999-09-
19 section 270.
ASTM1250-
1980 Table 54D
This table provides CTL factors for correcting volumes of lube oils at observed temperatures
to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a lube oil
 Density @ 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 800-1064 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Note: Enabling the “Canada API Limits” bay parameter will extend the temperature range
down to -40 C in accordance with Measurement Canada Bulletin: V-18-E rev.3 1999-09-
19 section 270.
