Toptech Systems MultiLoad II SCS User Manual

Chapter 9 – Weights & Measures
314
Firmware Version 3/4.31.37
Grem=M1
Trem=T1
Drem=D1 OR ((De * Ge) + (Dr * Gr)) / Gb
Nrem=Grem*VCFr(Trem,Drem)
Mrem=Nrem * Drem OR Mrem=Grem * D1
Where: Grem=Gross volume loaded for the Regular/Ethanol Meter
M1=Gross volume reported by meter M1
Trem=Temperature for the Regular/Ethanol Meter
T1= Volume weighted average temperature reported by probe T1
Drem=Density for the Regular/Ethanol Meter
D1=Volume weighted average Density measured OR specified for meter M1
((De * Ge) + (Dr * Gr)) / Grem=Volume weighted density for the Regular/Ethanol blend
(see Preset Level Parameter Compute Blend Density)
Nrem=Net volume loaded for the Regular/Ethanol Meter
VCFr=API Correction Table for Regular
Mrem=Mass loaded for the Regular/Ethanol Meter
Premium meter (Meter Level) values are reported as:
Gpm=M2
Tpm=T2
Dpm=D2 OR Dp
Npm=Gpm*VCFp(Tpm,Dpm)
Mpm=Npm * Dpm OR Mpm=Gpm * D2
Where: Gpm=Gross volume loaded for the Premium Meter
M2=Gross volume reported by meter M2
Tpm=Temperature for the Premium Meter
T2= Volume weighted average temperature reported by probe T2
Dpm=Density for the Premium Meter
D2=Volume weighted average Density measured OR specified for meter M2
Dp=Density specified for the Premium component
Npm=Net volume loaded for the Premium Meter
VCFp=API Correction Table for Premium
Mpm=Mass loaded for the Premium Meter
Blended product (Preset Level) values reported as:
Gb=Grem + Gpm (value not to be used for trade)
Tb=((Trem*Grem) + (Tpm*Gpm)) / Gb (value not to be used for trade)
Db=((Drem*Grem) + (Dpm*Gpm)) / Gb (value not to be used for trade)
Nb=Nrem + Npem
Mb=Mrem + Mpem
Where: Gb=Gross volume loaded for the blend
Tb=Temperature for the blend
((Trem*Grem) + (Tpm*Gpm)) / Gb=Volume weighted temperature for the blend
