Toptech Systems MultiLoad II SCS User Manual

Chapter 13 – Custom Logic
414
Firmware Version 3/4.31.37
Type
Input
Output
1
0
0
1
1
0
EXCLUSIVE OR
A.) Custom Logic Index
B.) Custom Logic Index
A
B
Output
0
0
0
0
1
1
1
0
1
1
1
0
Add
A.) Custom Logic Index
B.) Custom Logic Index
A + B
Subtract
A.) Custom Logic Index
B.) Custom Logic Index
A - B
Multiply
A.) Custom Logic Index
B.) Custom Logic Index
A x B
Divide
A.) Custom Logic Index
B.) Custom Logic Index
A ÷ B
EQUAL TO
A.) Custom Logic Index
B.) Custom Logic Index
Input
Output
A = B
1
A ≠ B
0
LESS THAN
A.) Custom Logic Index
B.) Custom Logic Index
Input
Output
A < B
1
A = B
0
A > B
0
GREATER THAN
A.) Custom Logic Index
Input
Output
A< B
0
A = B
0
A > B
1
LESSorEQUAL
A.) Custom Logic Index
B.) Custom Logic Index
Input
Outpt
A < B
1
A = B
1
A > B
0
GREATERorEQUAL
A.) Custom Logic Index
B.) Custom Logic Index
Input
Output
A < B
0
A = B
1
A > B
1
