Toptech Systems MultiLoad II SCS User Manual

Chapter 4 – General Configuration
95
Firmware Version 3/4.31.37
 This new selection groups the parameters together, so each parameter can be easily found. It is possible that
some parameters are under more than 1 group.
The Equipment Setup Menu will display:
Note: A typical MultiLoad II SMP bay would consist of one load arm or Preset, one main product Meter/control
valve connected to one Component and may have up to two Additives:
The following table shows the relationships between internal I/O board ports and the functional assignments:
AC Output
Port 0
Additive Injection Output 1
AC Output
Port 1
Additive Injection Output 2
AC Output
Port 2
N.O. Solenoid
AC Output
Port 3
N.C. Solenoid
DC Input
Port 4
Meter Channel A
DC Input
Port 5
Meter Channel B (optional)
DC Input
Port 6
Additive Meter Input 2
DC Input
Port 7
Additive Meter Input 1
SELECT PARAMETER LEVEL
All
Input/Output
Weights & Measures
Flow Control & Rates
Blending
API
Alarms
Next Prev Exit Enter
EQUIPMENT SETUP MENU
Bay
Preset
Meters
Components
Additives
Sampler
Next Prev Exit Enter
