Tormach 1100MX - Spindle Head Parts List

13: DIAGRAMS AND PARTS LISTS
©Tormach® 2020
Specifications subject to change without notice.
Page 233 Tormach 1100MX Operator's Manual (Version 0720A)
For the most recent version, see tormach.com/support
13.6 SPINDLE HEAD PARTS LIST
ID Description Quantity
1 1100 Head Casting (PN30323) 1
2 1100 Spindle Motor Mount (PN 30324) 1
3 Spindle Cover, 1100 (37690) 1
4 1100 Spindle Motor Pivot Plate Assembly (37714) 1
5 BT30 Spindle Cartridge Assembly, 1100MX (PN39590) 1
6 Wear Strip, Spindle Door (PN 38451) 2
7 Magnetic Encoder, Readhead (PN 38299) 1
8 Mill Coolant Manifold Assembly (PN 38346) (Optional) 1
9 Screw, Socket Head Cap, M10 × 1.5 - 30 (PN31894) 6
10 Screw, Socket Head Cap, M12 × 1.75 - 50 (PN32476) 6
11 Machine Screw, Socket, M8 × 1.25 - 30 (PN 30544) 6
12 Washer, Split Lock, M10 (PN 31684) 6
13 Washer, Split Lock, M12 (PN 30321) 6
14 Washer, Flat, M10 (PN 30919) 6
15 Washer, Flat, M12 (PN 32473) 6
16 Pin, Taper, 8 mm - 40 mm (PN30320) 2
17 Screw, M5 × 0.8 -14 (PN37901) 6
18 Screw, Button Head Cap (Flanged), M5 × 0.8 - 10, Stainless Steel (PN 38205) 2
19 1100MX/770MX Power Drawbar Kit (PN 50433) 1
20 1100MX Spindle Belt(PN50402) 1
