4: INSTALLATION
We do not recommend setting the backlash greater than 90
arc-seconds (1.5 arc-minutes). It won't improve the life of the
mechanism, and could result in chatter during machine
operations.
Mount the Rotary Table
1. Prevent rust from forming on the machine table from
trapped water-based coolants: put a thin film of oil (WD-
40® or similar) on the surfaces.
2. Depending on your rotary table, do one of the following:
l
6 in. Rotary Table or 8 in. Rotary Table Put the
rotary table on the left side of the machine table.
l
6 in. Super Spacer Rotary Table, 8 in. Super
Spacer Rotary Table, 6 in. Tilting Rotary Table,
or 8 in. Tilting Rotary Table Put the rotary table on
the right side of the machine table.
3. Loosely attach the rotary table toe clamps to the
machine table.
Note: The components are left loose so that
you can adjust the rotary table.
4. Attach a magnetic dial indicator to the spindle head of
the machine.
5. Put the dial indicator on the rotary table so that it will
measure across the platter of the rotary table.
6. Jog the machine from side-to-side in the Y direction to
indicate across the platter.
7. Use a dead blow hammer to tap the rotary table and
adjust its position and reduce any misalignment
determined in Step 6.
8. Completely tighten the rotary table toe clamps to secure
the rotary table to the machine table.
Install the A-Axis Motor Driver
WARNING! Electrical Shock Hazard: You must power
off the machine before making any electrical
connections. If you don't, there's a risk of
electrocution or shock.
1. Power off the machine and the PathPilot controller.
a. Push in the Emergency Stop button on the operator
box, which removes power to motion control.
b. From the PathPilot interface, select Exit.
c. Turn the Main Disconnect switch to OFF on the side
of the electrical cabinet.
2. Verify that you've correctly set the DIP switches on your
stepper driver as detailed in Set the Driver DIP Switches.
3. Remove the top, right, and middle (above the DC-BUS
board) wire trough covers in the electrical cabinet.
4. Find the ribbon cable (labeled 423.4) in the top wire
trough.
5. Find the green connector and wires in the right wire
trough.
6. Install the motor driver in the electrical cabinet with a #2
Phillips screwdriver.
7. Connect the ribbon cable and the power connector into
the motor driver.
8. Find wire 241 and wire 240 in the middle wire trough
(above the DC-BUSboard).
9. Connect the power wire spade connectors to the DC-BUS
board as follows:
a. Connect wire 241 (brown) to A+ terminal
b. Connect wire 240 (blue) to A- terminal
10. Put back the wire trough covers.
Verify the Installation
1. Make sure that all wires on the motor driver and the DC-
BUSboard are completely connected.
2. Replace the wire trough covers.
3. Connect the rotary table to the A-Axis Encoder connector
on the side of the electrical cabinet.
4. Power on the machine and the PathPilot controller.
a. Turn the Main Disconnect switch to ONon the side of
the electrical cabinet.
b. Twist out the Emergency Stop button on the operator
box, which enables movement to the machine axes
and the spindle.
c. Press the Reset button on the operator box.
d. Bring the machine out of reset and reference it.
©Tormach® 2020
Specifications subject to change without notice.
Page 67 Tormach 1100MX Operator's Manual (Version 0720A)
For the most recent version, see tormach.com/support
