13.16 Y-AXIS ASSEMBLY PARTS LIST
ID Description Quantity
1 1100 Machine Base (PN30399) 1
2 Y-Axis Motor Mount (PN 30445) 1
3 Ball Screw Coupler (PN 30362) 1
4 Bearing, Angular Contact, 7202B (P6), 15 mm × 35 mm × 11 mm (PN 30373) 2
5 X-Y Ball Screw Bearing Spacer (PN 30429) 1
6 X-Y Ball Screw Bearing Cover Plate (PN30423) 1
7 Y-Axis Ball Screw Assembly, 1100 (PN38800) 1
8 Bearing Nut, M14 × 1.5, Tab Lock (PN30363) 2
9 Ball Screw End Stop Clamp (PN30433) 1
10 Y-Axis Ball Screw Back Bumper, 1100 (PN30446) 1
11 Motor Mount Cover Plate (PN 30418) 1
12 X-/Y-Axis Ball Screw End Bumper, 1100 (PN 30400) 1
13 Bearing Nut Lock Washer, M14 (PN30364) 1
14 Y-Axis Cover Plate (PN30406) 1
15 Y-Axis Bellows Spacer (PN30404) 2
16 X-Y Bearing Nut Sleeve (PN30444) 1
17 X-Y End Bumper Washer (PN 30401) 1
18 Y-Axis Limit Switch Flag (PN 30450) 2
19 Fitting, Oil, Tee (PN30398) 1
20 Screw, Button Head Cap, M5 × 0.8 - 12 (PN37716) 4
21 Taper Pin, 8 mm × 30 mm (PN 30428) 2
22 Screw, Pan Head Machine, M6 × 1 - 40 (PN 30405) 4
23 Screw, Pan Head Machine, M4 × 0.7 - 12 (PN30403) 12
24 Y-Axis Servo Motor, 1100 (PN 38701) 1
25 Y-Axis Way Cover, 1100 (PN30578) 2
26 Screw, Socket Head Cap, M6 × 1 - 16 (PN33117) 2
27 Washer, Split Lock, M5 (PN 31572) 10
28 Washer, Flat, M5 (PN39305) 4
29 Screw, Socket Head Cap, M5 × 0.8 - 20 (PN 30357) 4
