13.12 SPINDLE MOTOR COVER PARTS LIST
ID Description Quantity
1 1100 Rear Spindle Cover (PN 37691) 1
2 1100 Front Spindle Cover (PN 37692) 1
3 1100 Upper Drag Chain Mount (PN 38456) 1
4 Spindle Motor Cover Latch (PN 31199) 1
5 Y-Axis Limit Switch (PN30461) 1
6 Cover Dog (PN 37695) 1
7 Bumper, Push-In, 16 mm × 8.5 mm, Rubber (PN 38450) 2
8 Spindle Door Latch Guard (PN 38878) 1
9 Cover Hinge (PN 37693) 2
10 Cover Pivot (PN 37694) 2
11 Cover Axel (PN 37696) 2
12 Spindle Motor Cover Lid Support (PN 38446) 1
13 Lid Support Bushing (PN 38447) 2
14 Lid Support Washer (PN 38448) 2
15 Screw, Button Head Cap (Flanged), M5 × 0.8 - 10, Stainless Steel (PN 38205) 20
16 Screw, Button Head Cap (Flanged), M5 × 0.8 - 8 (PN 38889) 4
17 Screw, Button Head Cap (Flanged), M5 × 0.8 - 12 (PN38890) 2
18 1100M Drag Chain (PN38464) 1
19 Screw, Button Head Cap, M4 × 0.7 - 10 mm (PN 38904) 4
