108
is shown on the right side of the voltage.
If the registration failed due to sensor failure, “SENSOR ERROR” is displayed and the ERROR LED turns on.
The ERROR LED turns off when the upper-level menu is displayed.
The setting range is as below.
9.7.2.3 PAPER END LEVEL
Paper end level of the transmissive sensor and the reflective sensor is registered.
Remove any media from the printer.
The display of the currently detected value is updated every 200 msec.
Hold down the [ENTER] key for 3 seconds or more.
When the registration of the “paper end level” is completed, “Adjustment Complete” is displayed and an
asterisk (*) is shown on the right side of the voltage.
If the registration failed due to sensor failure, “SENSOR ERROR” is displayed and the ERROR LED turns on.
The ERROR LED turns off when the upper-level menu is displayed.
The setting range is as below.
9.7.2.4 RIBBON SENSOR
Ribbon level is registered.
Set the ribbon so that the ribbon end sensor can detect a ribbon area.
The display of the currently detected value is updated every 200 msec.
Hold down the [ENTER] key for 3 seconds or more.
When the registration of the “ribbon level” is completed, “Adjust Complete” is displayed and an asterisk (*) is
shown on the right side of the voltage.
If the registration failed due to sensor failure, “SENSOR ERROR” is displayed and the ERROR LED turns on.
The ERROR LED turns off when the upper-level menu is displayed.
The setting range is as below.
9.7.3 THRESHOLD SELECT
・ REFLECT Threshold value for the reflective sensor is selected.
・ TRANS. Threshold value for the transmissive sensor is selected.
9.7.3.1 REFLECT
・ MANUAL THRESHOLD Threshold set in the manual threshold setting mode is used.
・ By COMMAND Threshold set by command is used.
9.7.3.2 TRANS.
・ MANUAL THRESHOLD Threshold set in the manual threshold setting mode is used.
・ By COMMAND Threshold set by command is used.
