Toshiba B-EX6T Series User Manual

45
7.4 SENSOR ADJUSTMENT SCREEN
The sensor adjustment screen is used only when the level of the media sensors on the printer is required to be
adjusted.
It is comprised with the following :
Display example
REFLECTIVE SENSOR
4.3V
Set a blank label
[ENTER] for 3sec
Display
Before adjustment
REFLECTIVE SENSOR
4.3V
Set a blank label
[ENTER] for 3sec
After adjustment
REFLECTIVE SENSOR
4.5V *
Adjust Complete
Key function (before adjustment)
Key
Substitute Key
Function
[MODE]
None
Displays the top menu.
[CANCEL]
None
Displays the upper-level menu.
[ENTER]
None
When held down for 3 seconds or more, the sensor adjustment
is performed.
When this key is released within 3 seconds, the screen returns
to the upper-level menu.
[UP]
None
No function
[DOWN]
None
No function
[LEFT]
None
No function
[RIGHT]
None
No function
Key function (after adjustment)
Key
Substitute Key
Function
[MODE]
None
Displays the top menu.
[CANCEL]
None
Displays re-adjustment menu.
[ENTER]
None
Displays the upper-level menu.
[UP]
None
No function
[DOWN]
None
No function
[LEFT]
None
No function
[RIGHT]
None
No function
Notes:
1. The symbol “*” shown on the right side of the adjustment value indicates the completion of adjustment.
2. The voltage value being selected is updated approximately every 200 msec. interval.
Sensor level
Message
Title
