Page #128 background image
127
The number of tag being read/The total number of tags read
(Mostly, only 1 tag is read.)
For the UHF module, AGC value of the read tag is displayed with decimal number.
Data displayed on the 3rd and 4th lines are expressed with hex. code. (16 digits x 2 lines = 32 digits)
The displayed data differs depending on the module type.
B-EX6T1/T3
RFID module
Displayed data
B-EX706-RFID-U4-R
B-EX706-RFID-U4-EU/US/AU-R
EPC code of EPC area
B-EX4T1
RFID module
Displayed data
B-EX700-RFID-H1-QM-R
Tag ID
B-EX700-U2-EU/US-R
B-EX700-RFID-U4-R
B-EX700-RFID-U4-EU/US/AU-R
U4 module preinstall model
(B-EX4T1/EX4T2-GS18/TS18-CN-R)
EPC code of EPC area
In the case of 16 bytes or more data, only the first 16 bytes are displayed. When data is less than16
bytes, the vacant digits will be filled with spaces.
If more than one tag is read at one time, especially when short-pitch tags are used, pressing the [UP] or
[DOWN] key shows the other tags data.
9.10.2 MODULE
The information related to the module setting is displayed.
The menu structure of MODLE
Menu item
<7>RFID
MODULE
MODULE TYPE
COUNTRY
TAG
RF CHANNEL
9.10.2.1 MODULE TYPE
B-EX6T1/T3
NONE No RFID module is installed.
HF band(H1) Not supported
HF band(H2) Not supported
UHF band (U2/U4) B-EX706-RFID-U4-R (Japan)
B-EX706-RFID-U4-EU-R (Europe)
B-EX706-RFID-U4-US-R (U.S.A)
B-EX706-RFID-U4-AU-R (Australia)
B-EX4T1
NONE No RFID module is installed.
HF band(H1) B-EX700-RFID-H1-QM-R
