4 Replacement Procedures 4.4 HDD
8. Remove the following screws securing the HDD holder and remove the HDD holder
from HDD.
 M3.0x4.0Z FLAT BIND screw x4
M3.0x4.0Z FLAT BIND
M3.0x4.0Z FLAT BIND
HDD holder
HDD
Figure 4-6 Removing a HDD
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 4-15
