4.4 HDD 4 Replacement Procedures
8. Remove the following screws and separate the HDD holder from the HDD assembly.
• M3.0×4S S-FLAT BIND screw ×4
M3.0x4S S-FLAT BIND
M3.0x4S S-FLAT BIND
HDD
HDD holder
Figure 4-6 Removing the HDD
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-15
