4 Replacement Procedures 4.4 HDD
4-16 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Installing the HDD
The following describes the procedure for installing the HDD (See Figure 4-4 to 4-6).
1. Install the HDD to the HDD holder and secure it with the following screws.
• M3.0×4S S-FLAT BIND screw ×4
NOTE: Although they are 3mm head screws, screw torque must be set in 0.294 N·m
(3.0Kgf·cm) for four screws securing the HDD holder.
2. Slide the HDD-2 assembly into the HDD-2 slot and connect it carefully to the
connector CN1860 on the system board.
3. Secure the HDD-2 assembly with the following screw.
• M2.5×6B FLAT BIND screw ×１
4. Install the HDD-2 slot cover and secure it with the screw (with e-ring).
5. Insert the HDD-1 assembly into the HDD-1 slot and connect it carefully to the
connector CN1850 on the system board.
6. Secure the HDD-1 assembly with the following screw.
• M2.5×6B FLAT BIND screw ×１
7. Install the HDD-1 slot cover and secure it with the screw (with e-ring).
