4 Replacement Procedures
4.17 Optical disk drive
2.
Re
m
ove the following
screw
securing the ODD assembly.
•
M2.5
×
6B
FLAT BIND screw
×
1
3.
Remove the
ODD assembly
from the connector
CN1810
on the system board.
CN1810
ODD assembly
M2.5x6B FLAT BIND
Figure 4-25 Removing the ODD assembly
4-42
[CONFIDENTIAL
]
QOSMIO G30 Mai
ntenance Man
ual (960-54
6)
287
