4.36 Fluorescent Lamp 4 Replacement Procedures
4. Turn the LCD module face up and remove the LCD panel (F) from the backlight unit
(E).
CAUTION: Take following care in handling LCD panel.
1) Do not pull the circuit board and driver (when moving it, hold the edge
of glass).
2) Be careful not to damage by ESC.
Be careful not to
damage by ESC
Figure 4-63 Replacing 17.1 Inch Sharp fluorescent lamp (4)
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-93
