4 Replacement Procedures 4.36 Fluorescent Lamp
3. Turn the LCD module face down and remove the screw (C) fixing the board. Then
open the bent portion of the TCP of the board and remove the backlight.
The torque loosening screw shall be
0.12 N m
Figure 4-62 Replacing 17.1 Inch Sharp fluorescent lamp (3)
4-92 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
