Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-5
Table C-2 Memory connector 1 (200-pin) (2/3)
PIN No. Signal name I/O PIN No. Signal name I/O
63
A
DQ28-B1P I/O 64
A
DQ25-B1P I/O
65 GND - 66 GND -
67 ADM3-B1P I 68 ADQS3-B1N I/O
69 N.C. - 70 ADQS3-B1P I/O
71 GND - 72 GND -
73 ADQ26-B1P I/O 74 ADQ29-B1P I/O
75 ADQ27-B1P I/O 76 ADQ31-B1P I/O
77 GND - 78 GND -
79 MCKE2-B1P I 80 MCKE3-B1P I
81 1R8-B1V I 82 1R8-B1V I
83 N.C. - 84 N.C -
85 ABS2-B1P I 86 N.C -
87 1R8-B1V I 88 1R8-B1V I
89 AMA12-B1P I 90 AMA11-B1P I
91 AMA09-B1P I 92 AMA07-B1P I
93 AMA08-B1P I 94 AMA06-B1P I
95 1R8-B1V I 96 1R8-B1V I
97 AMA05-B1P I 98 AMA04-B1P I
99 AMA03-B1P I 100 AMA02-B1P I
101 AMA01-B1P I 102 AMA00-B1P I
103 1R8-B1V I 104 1R8-B1V I
105 AMA10-B1P I 106 ABS1-B1P I
107 ABS0-B1P I 108 ARAS-B1N I
109 AWE-B1N I 110 MCS2-B1N I
111 1R8-B1V I 112 1R8-B1V I
113 ACAS-B1N I 114 MODT2-B1P I
115 MCS3-B1N I 116 AMA13-B1P I
117 1R8-B1V I 118 1R8-B1V I
119 MODT3-B1P I 120 N.C -
121 GND - 122 GND -
123 ADQ32-B1P I/O 124 ADQ36-B1P I/O
125 ADQ33-B1P I/O 126 ADQ37-B1P I/O
127 GND - 128 GND -
129 ADQS4-B1N I/O 130 ADM4-B1P I
