Appendices Appendix C Pin Assignments
C-6 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Table C-2 Memory connector 1 (200-pin) (3/3)
PIN No. Signal name I/O PIN No. Signal name I/O
131
DQS4-B1P I/O 132 GND -
133 GND - 134 ADQ38-B1P I/O
135 ADQ34-B1P I/O 136 BDQ39-B1P I/O
137 ADQ35-B1P I/O 138 GND -
139 GND - 140 ADQ44-B1P I/O
141 ADQ40-B1P I/O 142 ADQ45-B1P I/O
143 ADQ41-B1P I/O 144 GND -
145 GND - 146 ADQS5-B1N I/O
147 AMD5-B1P I 148 ADQS5-B1P I/O
149 GND - 150 GND -
151 ADQ43-B1P I/O 152 ADQ46-B1P I/O
153 ADQ42-B1P I/O 154 ADQ47-B1P I/O
155 GND - 156 GND -
157 ADQ48-B1P I/O 158 ADQ52-B1N I/O
159 ADQ54-B1P I/O 160 ADQ53-B1N I/O
161 GND - 162 GND -
163 N.C. - 164 MCK4-B1P I
165 GND - 166 MCK4-B1N I
167 ADQS6-B1N I/O 168 GND -
169 ADQS6-B1P I/O 170 ADM6-B1P I
171 GND - 172 GND -
173 ADQ51-B1P I/O 174 ADQ50-B1P I/O
175 ADQ55-B1P I/O 176 ADQ49-B1P I/O
177 GND - 178 GND -
179 ADQ57-B1P I/O 180 ADQ56-B1P I/O
181 ADQ60-B1P I/O 182 ADQ61-B1P I/O
183 GND - 184 GND -
185 ADM7-B1P I 186 ADQS7-B1N I/O
187 GND - 188 ADQS7-B1P I/O
189 ADQ58-B1P I/O 190 GND -
191 ADQ59-B1P I/O 192 ADQ62-B1P I/O
193 GND - 194 ADQ63-B1P I/O
195 SMBDAT-P3P I/O 196 GND -
197 SMBCLK-P3P I/O 198 GND -
199 P3V I 200 P3V I
