Appendix J Maintenance of TOSHIBA RAID Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] J-11
Physical Drive
In Physical Drive, the condition of RAID array is displayed by array. The following
items are displayed.
Table J-3 Items displayed in Physical Drive
Explanation
Port Displays the port number of Serial ATA connected to the drive.
Assign Displays the array number and drive number of array that the drive
is incorporated. The display format is LD [Array number]
[Drive number]. For example, [LD0-1] means the disk drive 1 of
Array 0.
Status Displays the drive status. The followings are displayed.
-ONLINE: The drive is working normally.
-OFFLINE: The drive is not configured as array and is not used.
-FAIL: The drive is failed and dose not work.
-REBUILDING: The drive is been rebuilding by data of normal drive
or the rebuilding is suspended.
-UNKNOWN: There is controversy in the RAID information of other
drive and the status is not decided. It is displayed when this drive
was removed and used in the past. When this drive has been
found good one, setting to OFFLINE is possible by executing
[Force Offline].
Size Displays the capacity of drive.
Model Displays the model number of drive.
Rev Displays the firmware revision of drive.
Progress Displays the progress of rebuilding and Check media.
