E6582233
J-13
10
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference
F710 0710
Initial panel
display selection
- - 0: Operation frequency (Hz/free unit)
1: Output current (%/A)
2:
Frequency setting value (Hz/free unit)
3 to 17: -
18: Arbitrary code from communication
19 to 33: -
34: Number of starting
35 to 51: -
52: Frequency setting value /
Operation frequency (Hz/free unit)
0 6.20.5
8.3.2
F711 0711
Status monitor 1 - - 0: Operation frequency (Hz/free unit)
1: Output current (%/A)
2:
Frequency setting value (Hz/free unit)
3: Input voltage (DC detection) (%/V)
4:
Output voltage (command value) (%/V)
5: Input power (kW)
6: Output power (kW)
7: Torque (%)
8: Torque current (%/A)
9 to 11: -
12: Frequency setting value (after
compensation) (Hz/free unit)
13 to 22: -
23: PID feedback value (Hz/free unit)
24 to 26: -
27: Drive load factor (%)
28 to 33: -
34: Number of starting
35 to 51: -
52: Frequency setting value /
Operation frequency (Hz/free unit)
2 8.2.1
8.3.2
F712 0712
Status monitor 2 - - 1
F713 0713
Status monitor 3 - - 3
F714 0714
Status monitor 4 - - 4
F715 0715
Status monitor 5 - - 27
F716 0716
Status monitor 6 - - 0
F720 0720
Initial extension
panel display
selection
- - 0-52
(Same as f710)
0 6.20.5
8.3.2
F730 0730
Panel frequency
setting prohibition
()
- - 0: Permitted
1: Prohibited
0 6.20.1
F731 0731
Disconnection
detection of
extension panel
- - 0: Permitted
1: Prohibited
0
F732 0732
Local/remote key
prohibition of
extension panel
- - 0: Permitted
1: Prohibited
1
F733 0733
Panel operation
prohibition
(RUN/STOP keys)
- - 0: Permitted
1: Prohibited
0
F734 0734
Panel emergency
stop operation
prohibition
- - 0: Permitted
1: Prohibited
0
F735 0735
Panel reset
operation
prohibition
- - 0: Permitted
1: Prohibited
0
F736 0736
/
change prohibition
during operation
- - 0: Permitted
1: Prohibited
1
F738 0738
Password setting
()
- - 0: Password unset
1-9998
9999: Password set
0
F739 0739
Password
verification
- - 0: Password unset
1-9998
9999: Password set
0
