Toshiba TOSVERT VF-nC3E - Page 23

E6582233
A-10
1
VFNC3E-4015
P
, 4022P
★ Bend the clips on the wiring port of the terminal cover to connect the PA/+, and PB terminals.
VFNC3E-4037P
，4055P
W
/
T3
V
/
T2U
/
T1PB
PA
/+
TL
/
3S
/
L2R
/
L1
★ Bend the clips on the wiring port of the terminal cover to connect the PA/+, and PB terminals.
M3.5 screw
Earth
terminal
(M4 screw)
Earth
terminal
(M4 screw)
Earth
terminal
(M5 screw)
M4 screw
Earth
terminal
(M5 screw)
