E6582233
A-11
1
VFNC3E-4075P，4110P
★ Bend the clips on the wiring port of the terminal cover to connect the PA/+ and PB terminals.
When using a crimping terminal, be sure to cover the fastener with an insulating tube or use an insulated
crimping terminal.
M5 screw
Earth
terminal
(M5 screw)
M5 screw
