MAINTENANCE MANUAL
! CAUTION
• With the exception of the encoder backup batteries and greases, all parts
listed in previous page are custom-made to Toshiba Machine specifications.
Contact Toshiba Machine at order entry.
• Parts replacement work must be done by Toshiba Machine service engineer.
Toshiba Machine’s warranty does not cover failures, accidents or any
damages.
5.2 List of Replacement Parts – Controller
Part name No. Type Q'ty Remarks
PS1 (Switching power supply)
1
LEB100F-0524 1
Main power switch 3
IR-11-A8-25-1BF 1
Lithium battery 4
ER6C WK27 1
Fuse 5
51NM030H 1 For X8GC printed
board
Printed board 6
X8GC (Main control) Y610A4000 1 Type N
X8GC (Main control) Y610A4020 1 Type P
X8GN (I/O board) Y610A40A0 1 Type N
X8GI (I/O board) Y610A40B0 1 Type P
X8G1A(30A) (Servo) Y610A40D0 1 Axis 1
X8G2A(20A) (Servo)
Y610A40F0
1 Axis 2
X8G2B(15A) (Servo)
Y610A40G0
2 Axes 3, 4
X8GH (Servo power
supply)
Y610A4050 1
X8GM (Mother board) Y610A4060 1
Operation panel unit
7
TS3000CP1 Y610A4080 1
Teach pendant
8
TP1000 Y610A4300 1 With 5 m-long
cable
System disk
9
TS3000SYS 1
.
STE 85306
– 112 –
