Class of Service Configuration
3-151
3
Web – Click Priority, IP Precedence Priority. Select an entry from the IP Precedence
Priority Table, enter a value in the Class of Service Value field, and then click Apply.
Figure 3-90 Mapping IP Precedence Priority Values
CLI – The following example globally enables IP Precedence service on the switch,
maps IP Precedence value 1 to CoS value 0 (on port 1), and then displays the IP
Precedence settings.
Note:
Mapping specific values for IP Precedence is implemented as an interface
configuration command, but any changes will apply to the all interfaces on the
switch.
Console(config)#map ip precedence 4-204
Console(config)#interface ethernet 1/1 4-131
Console(config-if)#map ip precedence 1 cos 0 4-206
Console(config-if)#end
Console#show map ip precedence ethernet 1/1 4-209
Precedence mapping status: enabled
Port Precedence COS
--------- ---------- ---
Eth 1/ 1 0 0
Eth 1/ 1 1 0
Eth 1/ 1 2 2
Eth 1/ 1 3 3
Eth 1/ 1 4 4
Eth 1/ 1 5 5
Eth 1/ 1 6 6
Eth 1/ 1 7 7
Console#
