Priority Commands
4-187
4
Command Usage
WRR controls bandwidth sharing at the egress port by defining scheduling
weights.
Example
This example shows how to assign WRR weights to priority queues 0 - 2:
Related Commands
show queue bandwidth (4-188)
queue cos-map
This command assigns class of service (CoS) values to the priority queues (i.e.,
hardware output queues 0 - 3). Use the no form set the CoS map to the default
values.
Syntax
queue cos-map queue_id [cos1 ... cosn]
no queue cos-map
• queue_id - The ID of the priority queue.
Ranges are 0 to 3, where 3 is the highest priority queue.
• cos1 .. cosn - The CoS values that are mapped to the queue ID. It is a
space-separated list of numbers. The CoS value is a number from 0 to 7,
where 7 is the highest priority.
Default Setting
This switch supports Class of Service by using four priority queues, with
Weighted Round Robin queuing for each port. Eight separate traffic classes
are defined in IEEE 802.1p. The default priority levels are assigned according
to recommendations in the IEEE 802.1p standard as shown below.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Console(config)#queue bandwidth 6 9 12
Console(config)#
Table 4-63 Default CoS Values to Egress Queues
Queue
0123
Priority
1,20,34,56,7
