7 Software Utilities
52 Trimble R6/R7 GPS and Trimble R8 GNSS Receivers User Guide
Trimble R7 GPS Receiver Operation
9. Click Menu to select another operation, or click Exit to quit WinFlash.
10. If you click
Exit, another screen appears asking you to confirm that you want to
quit. Click
OK.
70.1 Adding frequencies for the 450 MHz internal radio
If your receiver has the optional internal radio installed, you can use the WinFlash
utility to add receiving frequencies to the default list:
1. Start the WinFlash utility. The Device Configuration dialog appears.
2. From the Device type list, select Trimble R7 GPS receiver.
3. From the PC serial port field, select the serial (COM) port on the computer that
the receiver is connected to.
4. Click
Next.
The Operation Selection screen appears. The Operations list shows all of the
supported operations for the selected device. A description of the selected
operation is shown in the Description field.
5. Select Configure Radio and then click
Next.
The Frequency Selection dialog appears:
