CHAPTER
10
Trimble R6/R7 GPS and Trimble R8 GNSS Receivers User Guide 65
Cables and Connectors 10
In this chapter:
Q Port 1, 2, and 3 connectors
Q Power/serial data cable
Q Event marker/1PPS cable
Q GPS antennas and cables
This chapter provides pinout information for the
Trimble R7 GPS receiver standard and optional
cables. This information can be used to build
special cables for connecting the receiver to
devices and instruments not supported by the
standard and optional cables.
